Part Number:XBAIT197MA
RSR's newest Active Series can be used with the factory AVS and DDS system equipped on some models of Lexus, Toyota and Infiniti. The AVS and DDS systems do not function on current aftermarket shocks and coilovers, but RSR Active Series helps to retain the factory controls. Now the dampening and control systems still function, while providing you with a comfortable ride and performance.
Damper force is preset/non adjustable on the Basic*i Active
Compatibility:2014-2020 Lexus IS350 F-Sport AWD
Preset Approximate Height From RS-R:
Front-30mm to -35mm (-1.2in to -1.4in)
Rear-35mm to -40mm (-1.4in to -1.6in)
Maximum Adjustment Ranges:
Front0 to -100mm (0in to -4.0in )
Rear0 to -100mm (0in to -4.0in)
Recommended Adjustments for Optimal Ride-ability:
Front-10mm to -60mm (-0.4in to -2.4in)
Rear-10mm to -55mm (-0.4in to -2.2in)
Spring Rates:
Front10.0kg/mm
Rear8.30kg/mm
Compatible with Factory AVS System. Preset Damper Force Adjustment
