10-16 BMW 5 Series F10 AWD GodSpeed Coilovers- MAXX
GodSpeed Coilovers- MAXX For The 10-16 BMW 5 Series F10 AWD
Part Number: MMX3900-A
Godspeed Project's MAXX is their premier fully adjustable coilover kit. These coilovers are designed to be a street friendly race built coilover at an affordable price. Maxx coilovers feature a monotube damper that is made out of a oversized 53mm cartridge with a 44mm internal piston providing maximum damper response. The cold-bent springs are made from high strength SAE9252 steel to optimize the balance between performance and comfort. Using high quality shock oil made in Italy, Godspeed coilovers can guarantee exceptional damper performance at any temperature on and off the track. The top of the shock is attached to the car using a high quality top hat that features a high performance bearing pillow ball mount (when applicable). The bottom shock brackets are made out of a T7075 forged aluminum or high quality steel brackets for lighter weight without sacrificing durability which also includes brake line brackets (when applicable). The MAXX coilovers offer 40 level of damper adjustability which allow you to fine tune ride quality to your needs.
Features:
- Spring rates: Front: 12 kg/mm / Rear: 9 kg/mm
- Lowering only, will not be stock height or raise vehcile
- 40 precise levels of damper adjustment
- Monotube shock design
- Anodized shock body
- Lightweight aluminum shock components and T7075 forged aluminum / carbon steel brackets
- 52mm carbon steel shock body with a 44mm internal piston
- Independent ride height and spring preload adjustments
- Italian IP F.A made shock oil with a high viscosity index
- 1 Year Warranty from Date of Purchase
SPECIAL NOTES | No |
---|---|
DAMPING LEVELS | 40 Levels |
HEIGHT ADJUSTMENT | Yes |
SPRING RATE(FRONT) | 12 kg/mm (672 lbs/inch) |
SPRING RATE(REAR) | 8 kg/mm (448lbs/inch) |
SPRING LENGTH(FRONT) | 180 mm |
SPRING LENGTH(REAR) | 200 mm |
CAMBER PLATE(FRONT) | No |
CAMBER PLATE(REAR) | No |
SPRING INNER DIAMETER(FRONT) | 62 mm (2.44 inch) |
SPRING INNER DIAMETER(REAR) | 62 mm (2.44 inch) |
WARRANTY NOTE |
